Oklahoma City's best-selling residential garage door. Three-layer construction with polyurethane foamed-in-place insulation, pinch-resistant panels, TorqueMaster® Plus spring system, and a Lifetime Limited Warranty — in five panel designs and six signature color finishes.
| Construction | |
| Model Name | Wayne Dalton Classic Steel Model 9100 |
| Construction | Three-layer: 24-gauge galvanized steel face / polyurethane foamed-in-place insulation / ToughGard® composite backer |
| Steel Face | 24-gauge hot-dipped galvanized high-tensile embossed steel panels |
| Insulation | Polyurethane foamed-in-place — thermally superior to polystyrene, bonds permanently to steel skins |
| R-Value | R-9 (7' tall doors) · R-10 (8' tall doors) — calculated per DASMA TDS-163 industry standards |
| U-Factor | 0.26 — excellent thermal efficiency for Oklahoma's hot summers and cold winters |
| Backer | ToughGard® composite backer (Model 9100) — steel backer on upgraded Model 9605 |
| Pinch Resistance | Pinch-resistant panel joints engineered to deflect fingers away from section joints — Wayne Dalton pioneered this design |
| Panel Designs | |
| Available Styles | Short Panel · Long Panel · Flush Panel · Vertical Short Panel · Vertical Long Panel (5 designs) |
| Section Configuration | Four-panel (8'×7' doors) · Five-panel (8'×8' doors) — ask your DOORTEC specialist about additional sizes |
| Design Range | Classic to contemporary — suitable for New England cottages, traditional ranch, two-story colonials, and sleek modern homes |
| Panel Illustrations |
Short Panel
Long Panel
Flush Panel
Vert. Short
Vert. Long
|
| Available Sizes | |
| Standard Widths | 8' · 9' · 10' · 12' · 14' · 15' · 16' · 18' |
| Standard Heights | 7' · 8' |
| Custom Sizes | Non-standard sizes available — contact your DOORTEC specialist for custom sizing |
| Colors & Finishes | |
| Standard Colors | Black† · Sandstone · Gray · White · Almond · Brown (6 signature colors) |
| Black Finish | Features Cool Chemistry® technology — resists heat and UV degradation for long-lasting color |
| Color Note | Online swatches are digital reproductions and will vary by monitor. Always request physical color samples from your DOORTEC specialist for accurate matching. |
| Window Options | |
| Short & Flush Panel | 31 options: Arched Stockton Long · Ashton Long · Cascade Short & Long · Cathedral Short & Long · Clear Short & Long · Prairie Short & Long · Ruston Long · Sherwood Short & Long · Stockbridge Long (3 & 4-Lite) · Stockford Long · Stockton Long (4/6/8/12-Lite) · Stockton Long Arch (8-Lite) · Stockton Short · Waterton Short & Long · Williamsburg Long (2pc & 4pc) · Williamsburg Short (4pc & 8pc) · Wyndbridge Long (2/3/4pc) |
| Vertical Short Panel | 29 options: Same as Short/Flush except no Williamsburg Short or Wyndbridge 4pc |
| Long & Vertical Long Panel | 22 options: Arched Stockton Long · Ashton Long · Cascade Long · Cathedral Long · Clear Long · Prairie Long · Ruston Long · Sherwood Long · Stockbridge Long (3 & 4-Lite) · Stockford Long · Stockton Long (4/6/8/12-Lite) · Stockton Long Arch · Waterton Long · Williamsburg Long (2pc & 4pc) · Wyndbridge Long (2/3/4/5pc) |
| Max Window Coverage | Up to 50% of total door surface area |
| Glass Options | Clear · Gray Tinted · Satin Etched Privacy · Obscure (Clear, Satin Etched, and Obscure also available in tempered) · Optional insulated glass available |
| Placement Note | Clear windows can be arranged horizontally or vertically on Short, Long, and Flush panels. Vertical windows placed as special order. Bottom section windows require DSB 1/8", tempered, or ½" insulated glass. |
| Availability | Not all window styles available in all sizes or regions — confirm with your DOORTEC specialist |
| Safety & Performance | |
| Spring System | TorqueMaster® Plus Counterbalance — springs fully enclosed in powder-coated steel tube, preventing accidental release and injury |
| Anti-Drop Technology | Built-in anti-drop safety protection included as standard |
| High Cycle Spring Option | 25,000-cycle spring available — more than twice the lifespan of a standard torsion spring |
| Struts | Horizontal integral struts for long-term rigidity and smooth quiet operation |
| Bottom Seal | Standard flexible bottom weather seal — blocks drafts and debris year-round |
| Wind Load Option | WindSafe® structural reinforcements available — meets International Building Code, Florida Building Code, and Texas DOI requirements |
| Decorative Hardware | |
| Hardware Kits (7 styles) | Arrow · Aspen · Barcelona · Bean · Conifer · Fleur-de-Lis · Spear |
| Hammered Knockers | Arrow · Aspen · Barcelona · Conifer · Fleur-de-Lis · Spear |
| Lift Handles | Arrow · Aspen · Barcelona · Conifer · Fleur-de-Lis · Spear |
| Material | Black powder-coated steel with hand-hammered artisan finish |
| Kit Contents | 4 hinges + 2 pull handles per kit. Double car doors receive 2 complete kits. Additional accent pieces available separately. |
| Warranty | |
| Panel & Insulation | Limited Lifetime Warranty — against rust-through, cracking, splitting, and insulation degradation |
| DOORTEC Guarantee | All DOORTEC installations carry our own workmanship guarantee — if the installation isn't perfect, we'll return and fix it at no charge |
The 9100 Series is available in 6 signature paint colors. Online swatches are digital reproductions only — always request a physical color sample from your DOORTEC specialist before making your final selection.
† Black with Cool Chemistry®: Wayne Dalton's Cool Chemistry® technology protects the Black finish from heat absorption and UV degradation — keeping it looking bold and sharp for years without fading or chalking.
Wayne Dalton offers an incredible selection of window panels — 31 options for Short and Flush panels, 29 for Vertical Short, and 22 for Long and Vertical Long panels. A selection of available styles is shown below, followed by the full availability table by panel type.
Choice of single or double arch is available for arched top double car windows. Not all styles shown may be available in your area — confirm with your DOORTEC specialist.
* Also available in tempered. Optional insulated glass available for improved thermal performance. Clear windows can be arranged horizontally or vertically on Short, Long, and Flush panel designs. Vertical placement is a special order. Bottom section windows require DSB 1/8", tempered, or ½" insulated glass. Window styles are not interchangeable between panel designs.
Inspired by the artisanry of traditional blacksmiths, Wayne Dalton's decorative hardware collections lend a distinctive, yet subtle touch of individuality to your Classic Steel garage door. Every piece is forged from black powder-coated steel with a hand-hammered look. Kits include 4 hinges and 2 pull handles; double car doors receive 2 complete kits.
Additional accent pieces — corner brackets and clavos — are available to match or complement each collection. Pull handle fit in center stile is dependent upon design and size of door. Hardware images shown are representative — visit any DOORTEC Oklahoma City showroom to see physical hardware samples.
Wayne Dalton warrants your 9100 Series door panels against cracking or splitting due to rust-through for as long as the original purchaser owns the home — no time limit, no exceptions.
The polyurethane foamed-in-place insulation is warranted against degradation and R-value loss for the full life of the door under original ownership.
All springs, cables, tracks, hinges, and hardware components are covered under Wayne Dalton's limited hardware warranty for 12 months from the installation date.
When you purchase a Wayne Dalton 9100 Series door from DOORTEC, you're getting more than a product — you're getting over 60 years of Oklahoma City installation expertise behind it. Every installation is performed by our factory-trained, background-checked, and fully licensed and insured technicians. We've completed over 140,000 garage door installations across the OKC metro area.
| What's Included With Every DOORTEC Installation | |
| In-Home Measurement | A DOORTEC technician visits your home to take precise measurements and confirm all door specifications, opening type, and hardware requirements before the order is placed |
| Old Door Removal | We remove and haul away your existing garage door and hardware at no additional charge |
| Full Hardware Install | All springs, cables, tracks, rollers, hinges, and weatherstripping installed to Wayne Dalton factory specifications |
| Opener Compatibility | We verify your existing opener is compatible with the new door, or recommend an upgrade if needed — and install it same-day if desired |
| Balance & Safety Test | Full door balance check, force adjustment, and auto-reverse safety test performed before completion — every time |
| Site Cleanup | We remove all packaging materials, old door components, and debris — your driveway will be cleaner when we leave than when we arrived |
| Customer Walkthrough | Your installer walks you through door operation, maintenance tips, and how to register your Wayne Dalton warranty before leaving |
| Typical Project Timeline | |
| Measurement to Order | We submit your order immediately following the measurement visit — typically same day |
| Manufacturing Lead Time | Standard orders: 1–3 weeks. Non-standard sizes may require additional lead time. Ask your DOORTEC specialist for current availability. |
| Installation Duration | Most single and double residential installations are completed in 3–5 hours |
| Service Area | Oklahoma City · Edmond · Norman · Moore · Yukon · Midwest City · Guthrie · El Reno · Tulsa and surrounding communities |
The Wayne Dalton 9100 Series has been Oklahoma City's best-selling residential garage door for over a decade — and for good reason. Three-layer construction with polyurethane foamed-in-place insulation delivers an R-9 rating (R-10 on 8' doors) that keeps your garage noticeably cooler in Oklahoma's scorching summers and warmer during winter ice storms. Unlike polystyrene bead board insulation, the polyurethane foam bonds directly to both steel skins, preventing rattling, improving structural rigidity, and providing superior sound dampening against street noise.
The 24-gauge galvanized steel face paired with the ToughGard® composite backer gives the 9100 an excellent strength-to-weight ratio — durable enough for daily high-cycle use, yet light enough to reduce strain on your garage door opener. Integral horizontal struts at every section add backbone, and the pinch-resistant panel joint design — a Wayne Dalton innovation — provides meaningful protection for children and adults alike.
DOORTEC has installed thousands of 9100 Series doors across Oklahoma City, Edmond, Norman, Moore, Yukon, Midwest City, Guthrie, El Reno, and Tulsa. Our factory-trained technicians know this door inside and out, and our DOORTEC workmanship guarantee ensures your installation is perfect from day one.
The 9100 is an ideal choice for homeowners who want a reliable, energy-efficient, and great-looking steel garage door without overspending. It fits attached garages where insulation value matters, homes in Oklahoma City neighborhoods where curb appeal drives property value, and any situation where you want a door that's easy to maintain, resistant to Oklahoma weather extremes, and backed by a lifetime warranty.
With five panel designs — Short Panel, Long Panel, Flush Panel, Vertical Short Panel, and Vertical Long Panel — the 9100 suits everything from New England cottages and traditional ranch homes to two-story colonials and sleek contemporary builds. Choose from 6 signature colors: Black, Sandstone, Gray, White, Almond, or Brown.
Need help deciding between the 9100 and the 9605 double skin upgrade? Our specialists at any of our our Oklahoma City showroom can walk you through both options, show you physical samples, and give you an honest recommendation based on your home, your garage type, and your budget — at no charge.
